EPSA120050UE-P5P-EJ by cui inc.
Image is representational - see mfr. specs

EPSA120050UE-P5P-EJ

CUI Inc.

AC/DC Adapter - Wall Mount - 6 Watts: 12V @ 0.5A - EU Input Blades - Lvl V

RoHS Compliant
Packaging
Accessories
Discontinued & Replaced
Accessories
This product is backed by Ecco Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
CUI Inc.
Part No:
EPSA120050UE-P5P-EJ
RoHS:
Yes
HTS:
8504409510
COO:
CN
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Maximum Input Voltage:
264Vac
Maximum Output Power:
6 W
Output Connector Polarity:
Center Positive
Type:
Regulated-Switching
Thermal Protection:
No
Minimum Load (Amps):
0
Power Rating:
6 W
Output Type:
Fixed
Over Voltage Protection:
Yes
Family:
6W-Wall-EU-Blade
AC Input Current - Typical:
Not Spec'd
AC Input Voltage:
90 to 264
Safety Approvals:
CE, GS, TUV
AC Input Current - Maximum:
0.018A
Package Type:
Wall Plug
Output Connector Angle:
Straight
Minimum AC Input Voltage:
90
Maximum Input Current:
Not Spec'd
Efficiency:
Not Spec'd
Output Voltage:
12 VDC
Overload Protection:
Yes
Minimum Isolation Voltage:
3000Vac
Power Indicator:
No
Input Connector Type:
EU Blades
Mounting Style:
External
Output Cord Length:
1.53m (60.3in)
Output Current:
0.5 A
DC Input Voltage:
Not App
Number of Outputs:
1
Safety Class:
None
Load Regulation:
5.00 %
Grade:
Commercial
Maximum DC Input Voltage:
Not App
Power:
6 W
Typical Hold-Up Time:
10 ms
Input/Output Type:
AC/DC
Typical Inrush Current:
Not Spec'd
Output Connector Type:
Barrel - Female
Adapter Color:
Black
Mounting:
External
MOPP:
Not App
Dimensions L x W x H:
75.0 x 35.0 x 37.0 mm
Dimension:
75 x 35 x 37 mm
Maximum Output Current:
0.5 A
Line Regulation:
5.00 %
Short Circuit Protection:
Yes
Style:
WallMount
Input Frequency:
47 to 63 Hz
Ripple & Noise:
120 mV
CoC Tier:
No
Dimensions L x W x H(in):
2.96 x 1.38 x 1,46 in
Output Connector Diameters:
2.1 x 5.5 mm
Input Voltage:
90 to 264Vac
Operating Temperature:
0 to 40 °C
Dimensions LxWxH:
2.96 x 1.38 x 1,46 in
Minimum Input Voltage:
90Vac
DOE Efficiency Level:
V
PFC:
No
Minimum DC Input Voltage:
Not App
Maximum AC Input Voltage:
264
Life Cycle:
Discontinued & Replaced
AC/DC Adapter - Wall Mount - 6 Watts: 12V @ 0.5A - EU Input Blades - Lvl V
Search Keywords:
EPSA120050UEP5PEJ
  This product is not in stock and cannot be back-ordered
Please Note: Tariffs may apply for U.S. shipments
RECOMMENDED REPLACEMENT
SWI6-12-E-P5
SWI6-12-E-P5
