The 1-1393249-35 is a 25A push to reset only Thermal Circuit Breaker with maximum operating voltage is 50VDC or 250VAC, calibration will continuously carry 100% of rating, may trip between 101% and 145% of rated load, must trip at 145% at 25°C. Ten times rated current is resettable overload capacity, over 1500V RMS dielectric strength, endurance cycling is more than 1000 cycles at 200% of rated load. Quick connect 0.25-inch straight terminal with metal knurled nut or hex nut mounting hardware assembled to bushing. Cannot be manually tripped Button extends for visual trip indication Push button to reset breaker Single pole White with red rate marking, red trip band button Metal 7/16 x 0.5" long mounting bushing Applications Power Management, Power Management
