TT-2-PE-M-24DC

Modular terminal block with two-stage surge protection for one operated floating double conductor - disconnect knife on both signal paths - separate ground connection - nominal voltage: 24 V DC. .. see full description

RoHS Compliant

Packaging

Discontinued & Replaced

Accessories

Certificate of Compliance Guarantee

Product Attribute

Attribute Value Select Attribute

Products found: 0

Supplier:

Phoenix Contact

Part No:

TT-2-PE-M-24DC

RoHS:

Yes

HTS:

8536308000

COO:

ECCN:

EAR99

Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.

This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.

Life Cycle:

Discontinued & Replaced

Modular terminal block with two-stage surge protection for one operated floating double conductor, disconnect knife on both signal paths, separate ground connection, nominal voltage: 24 V DC. Color Black Current Rating 0.3 A Dimensions 92mm L x 6.2mm W x 66.45mm H For Use With Data/Comm Mounting Type DIN Rail Mount Number of Poles 2 Response Time 1 ns Standards IEC 61643-21 Supply Voltage 24 VDC Operating Temperature –40 to +80 °C Termination Screw Type Modular Voltage, Operating 30VDC ; 21VAC Weight 0.033042 kg Wire Size 24-14 AWG Current, Surge 10 kA
