SACC-M12MSD-4CON-PG 9-SH by phoenix contact
Image is representational - see mfr. specs
DATA SHEET

SACC-M12MSD-4CON-PG 9-SH

Phoenix Contact

Bus system connector - Ethernet/PROFINET CAT5 (100 Mbps) - 4-position - shielded - Plug straight M12 - D-coded - Screw connection - knurl material: Zinc die-cast - nickel-plated - cable gland Pg9 - external cable diameter 6 mm ... 8 mm .. see full description

RoHS Compliant
Packaging
Accessories
Accessories
This product is backed by Ecco Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
Phoenix Contact
Part No:
SACC-M12MSD-4CON-PG 9-SH
Alias/AKA:
1521261
RoHS:
Yes
HTS:
8536694020
COO:
CN
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Body Orientation:
Straight
Termination Method:
Screw
Gender:
PL
Contacts Classification:
4Signal
Maximum Current Rating:
4 A
Contact Material:
Brass
Contact Gender:
M
Shell Size / Insert Arrangement:
N/A
Operating Temperature:
-40 to 85 °C
Packaging:
N/A
Mating Style:
N/A
Contact Plating:
Gold
Mounting:
Cable Mount
Number of Ports:
1
Number of Contacts:
4
Type:
M12 Circular
Number of Terminals:
4
Strain Relief:
No
Ingress Protection:
IP67
Dimension:
56 x 20 mm
Family:
1521261
Maximum Voltage Rating:
60 V
Shell Material/Plating:
Brass/Nickel
The PHOENIX CONTACT part SACC-M12MSD-4CON-PG 9-SH is a reliable and efficient bus system connector designed for Ethernet and PROFINET CAT5 applications, offering a high-speed data transmission rate of up to 100 Mbps. This connector features a 4-position configuration, with a shielded design to ensure optimal signal integrity. It is equipped with a straight M12 plug with D-coding and a screw connection for secure and convenient installation.The knurled material is made of zinc die-cast and is nickel-plated for enhanced durability and corrosion resistance. The cable gland is of size Pg9, allowing for an external cable diameter of 6 mm to 8 mm, providing flexibility in cable selection.Overall, the SACC-M12MSD-4CON-PG 9-SH is a versatile and high-quality connector that is suitable for a wide range of industrial applications, offering reliable and efficient connectivity for Ethernet and PROFINET CAT5 networks.
Search Keywords:
SACCM12MSD4CONPG9SH
IN STOCK: 0
Factory Lead-Time
4 Weeks
Price (USD)
Quantity
Unit Price
Ext. Price
1 +
$32.11
$32.11
Please Note: Tariffs may apply for U.S. shipments
Product Guides
PDF Datasheet
