DATA SHEET

2866802

Phoenix Contact

Primary-switched QUINT POWER power supply for DIN rail mounting with SFB (Selective Fuse Breaking) Technology - input: 3-phase - output: 24 V DC/40 A .. see full description

RoHS Compliant
Packaging
Accessories
Accessories
This product is backed by Ecco Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
Phoenix Contact
Part No:
2866802
Alias/AKA:
QUINT-PS/3AC/24DC/40
RoHS:
Yes
HTS:
8504407018
COO:
TH
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Number of Outputs:
1
Packaging:
N/A
AC Input Voltage:
N/A
Operating Temperature:
-25 to 70 °C
Maximum Input Current:
N/A
Dimension:
176 x 96 x 130 mm
Output Voltage:
24 V
Output Type:
Fixed
Maximum AC Input Voltage:
575 V
Maximum Output Current:
40 A
Output Connector Type:
Screw Terminal Block
Maximum DC Input Voltage:
800 V
Type:
Switching
Minimum DC Input Voltage:
450 V
Input Frequency:
45 to 65 Hz
Input Connector Type:
Screw Terminal Block
Mounting:
DIN Rail
Minimum AC Input Voltage:
320 V
Maximum Output Power:
960 W
Family:
2866802
Minimum Isolation Voltage:
N/A
Efficiency:
94(Min) %
Pin Count:
12
Supplier Package:
N/A
DC Input Voltage:
N/A
Supplier Temperature Grade:
N/A
Style:
DIN Rail
The 2866802 is a 1-output DIN rail mount primary-switched QUINT Power Supply with SFB (Selective Fuse Breaking) technology. The 2866802 is a compact power supply unit with maximum functionality and adjustable voltage. With the SFB technology, six times the nominal current for 12ms, even the standard power circuit-breakers can now also be triggered reliably and quickly. Faulty current paths are switched off selectively, the fault is located and important system parts continue to operate. Comprehensive diagnostics are provided through constant monitoring of output voltage and current. This preventive function monitoring visualizes critical operating modes and reports them to the control unit before an error can occur. Quick tripping of the standard power circuit-breakers using dynamic power reserve SFB technology.
Search Keywords:
2866802
IN STOCK: 0
Factory Lead-Time
11 Weeks
Price (USD)
Quantity
Unit Price
Ext. Price
1 +
$1,059.34
$1,059.34
Please Note: Tariffs may apply for U.S. shipments
