MPS-200-15 by mean well
Image is representational - see mfr. specs
DATA SHEET

MPS-200-15

Mean Well

AC/DC Power Supply - 1 Output - 15V@9.4A - 200W - Medical

RoHS Compliant
Packaging
Accessories
Discontinued
Accessories
This product is backed by Ecco Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
Mean Well
Part No:
MPS-200-15
RoHS:
Yes
HTS:
8504409510
COO:
CN
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
OUT6 Amps:
Not App
Input/Output Type:
AC/DC
Operating Temperature:
-20 to 70 °C
Warranty:
3 Years
Input Connector Type:
Pin Header
Mounting:
Thru-hole
AC Input Voltage:
90 to 264 V
OUT5 Amps:
Not App
Termination Style:
Pin Header
Maximum Output Power:
200 W
Dimension:
177.8 x 107.2 x 35.5 mm
OUT1 VDC:
15
Product Weight:
660 g
OUT2 Range VDC:
Not App
IP Rating:
None
Maximum Output Current:
13.4 A
Number of Outputs:
1
OUT1 Amps:
13.4
Maximum Input Current:
3.5 A
Output Voltage Range:
14.25-16.5 VDC
Power Factor Correction:
0.95(Min)
Supplier Package:
N/A
OUT2 Amps:
Not App
Efficiency:
85(Typ) %
Type:
Switching,Regulated
OUT4 VDC:
Not App
Style:
Open Frame
Supplier Temperature Grade:
N/A
Maximum DC Input Voltage:
370 V
OUT5 VDC:
Not App
Family:
MPS-200
OUT4 Amps:
Not App
OUT2 VDC:
Not App
Packaging:
N/A
Output Connector Type:
Pin Header
OUT3 VDC:
Not App
Output Type:
Fixed
Maximum AC Input Voltage:
264 V
Input Frequency:
47 to 63 Hz
OUT6 VDC:
Not App
OUT1 Range VDC:
14.25-16.5
OUT3 Amps:
Not App
DC Input Voltage:
127 to 370 V
Output Voltage:
15 V
Pin Count:
28
Minimum Isolation Voltage:
4000 VAC
Minimum AC Input Voltage:
90 V
Minimum DC Input Voltage:
127 V
Life Cycle:
Discontinued
AC/DC Power Supply - 1 Output - 15V@9.4A - 200W - Medical
Search Keywords:
MPS20015
   This product has been discontinued by the supplier
This product is no longer being manufactured but there may be alternatives. We can help you, Contact Us.
