GST25B28-P1J by mean well
Image is representational - see mfr. specs
DATA SHEET

GST25B28-P1J

Mean Well

AC/DC Adapter - Desktop - 25 Watts: 28V @ 0.89A - IEC C320-C8 Inlet

RoHS Compliant
Packaging
Accessories
Accessories
This product is backed by Ecco Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
Mean Well
Part No:
GST25B28-P1J
RoHS:
Yes
HTS:
8504409510
COO:
CN
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
DC Input Voltage:
Not App
Dimensions L x W x H(in):
3.11 x 2.13 x 1.30 in
Style:
Desktop Adapter
Output Connector Diameters:
2.1x5.5 mm
Number of Outputs:
1
Minimum DC Input Voltage:
Not App
Maximum AC Input Voltage:
264
Power Indicator:
Yes
Typical Inrush Current:
45A(Max) at 230Vac
Output Current:
0.89 A
MOPP:
Not App
AC Input Current - Maximum:
0.58A
Minimum Load (Amps):
0
Dimensions LxWxH:
3.11 x 2.13 x 1.3 in
CoC Tier:
No
Input/Output Type:
AC/DC
Protection:
Overload,Over Voltage
Grade:
Commercial
Type:
Regulated-Switching
DOE Efficiency Level:
VI
Maximum DC Input Voltage:
Not App
Adapter Color:
Black
Overload Protection:
Yes
Output Cord Length:
1.8m (70.9in)
Short Circuit Protection:
No
Efficiency:
85.5(Typ) %
Load Regulation:
2.00 %
Maximum Input Voltage:
264Vac
Mounting:
External
Output Connector Angle:
Straight
PFC:
No
Pin Count:
N/A
Safety Class:
II
Minimum Isolation Voltage:
4242 VDC
Typical Hold-Up Time:
15/50ms at 115/230Vac
Operating Temperature:
-30 to 70 °C
Minimum AC Input Voltage:
90
Mounting Style:
External
Maximum Input Current:
Not Spec'd
AC Input Current - Typical:
Not Spec'd
Safety Approvals:
BSMI, CB, CCC, CE, GS, RCM, TUV
Ripple & Noise:
240 mV
Input Connector Type:
IEC 320-C8
Maximum Output Current:
0.89 A
Dimensions L x W x H:
79.0 x 54.0 x 33.0 mm
Supplier Package:
N/A
Output Connector Polarity:
Center Positive
Line Regulation:
1.00 %
Output Connector Type:
Barrel - Female
Output Voltage:
28 VDC
Input Frequency:
47 to 63 Hz
AC Input Voltage:
90 to 264
Power:
25 W
Input Voltage:
90 to 264 VAC
Family:
GST25B
Thermal Protection:
No
Output Type:
Fixed
Minimum Input Voltage:
90Vac
Packaging:
Carton
Power Rating:
25 W
Maximum Output Power:
25 W
Package Type:
Desktop
Dimension:
79 x 54 x 33 mm
Over Voltage Protection:
Yes
AC/DC Adapter - Desktop - 25 Watts: 28V @ 0.89A - IEC C320-C8 Inlet
Search Keywords:
GST25B28P1J
IN STOCK: 0
Factory Lead-Time
16 Weeks
Price (USD)
Quantity
Unit Price
Ext. Price
1
$13.70
$13.70
5
$13.00
$65.00
10
$12.50
$125.00
20 +
$12.10
$242.00
