SMI6-9-K-P5 by cui inc.
Image is representational - see mfr. specs
DATA SHEET

SMI6-9-K-P5

CUI Inc.

AC/DC Adapter - Wall Mount - 6 Watts: 9V @ 0.67A ++ NO AC INPUT BLADES ++ Lvl VI/T2

RoHS Compliant
Box Packaging
Accessories
Discontinued & Replaced
Accessories
This product is backed by Ecco Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
CUI Inc.
Part No:
SMI6-9-K-P5
RoHS:
Yes
HTS:
8504409510
COO:
CN
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
120
Package Type:
Box
Output Cord Length:
1.83m (72.1in)
Output Connector Polarity:
Center Positive
Thermal Protection:
No
Power Rating:
6 W
Operating Temperature:
0 to 40 °C
Output Type:
Fixed
AC Input Current - Typical:
Not Spec'd
Minimum Isolation Voltage:
4242Vdc/3000Vac
DOE Efficiency Level:
VI
Maximum Output Power:
6 W
Output Connector Angle:
Straight
Input Voltage:
90 to 264Vac
Ripple & Noise:
150 mV
Over Voltage Protection:
Yes
Line Regulation:
1.00 %
Input Frequency:
47 to 63 Hz
Dimensions L x W x H(in):
2.52 x 1.60 x 1.19 in
Output Connector Diameters:
2.1 x 5.5 mm
Minimum Input Voltage:
90Vac
Type:
Regulated-Switching
Grade:
Commercial
Maximum Output Current:
0.67 A
Output Current:
0.67 A
PFC:
No
Number of Outputs:
1
Input Connector Type:
Interchangeable-Order Separately
Maximum Input Voltage:
264Vac
Dimension:
64.1 x 40.5 x 30 mm
Typical Inrush Current:
Not Spec'd
Maximum DC Input Voltage:
Not App
AC Input Current - Maximum:
0.3A
Maximum AC Input Voltage:
264
Input/Output Type:
AC/DC
Short Circuit Protection:
Yes
Safety Approvals:
CCC, CE, cUL, GS, PSE, RCM, TUV, UL
Load Regulation:
5.00 %
Efficiency:
Not Spec'd
Style:
Interchangeable WallMount
Dimensions LxWxH:
2.52 x 1.594 x 1.181 in
Package Type:
Wall Plug
Special Features:
CoC Tier 2 Compliant, DoE Level VI Efficiency
Dimensions L x W x H:
64.1 x 40.5 x 30.0 mm
Output Voltage:
9 VDC
MOPP:
Not App
Mounting Style:
External
Overload Protection:
No
Power:
6 W
Safety Class:
None
Minimum AC Input Voltage:
90
Minimum DC Input Voltage:
Not App
Adapter Color:
Black
Minimum Load (Amps):
0
CoC Tier:
2
AC Input Voltage:
90 to 264
Family:
SMI6
Mounting:
External
Power Indicator:
No
Typical Hold-Up Time:
Not Spec'd
Output Connector Type:
Barrel - Female
DC Input Voltage:
Not App
Maximum Input Current:
0.3 A
Life Cycle:
Discontinued & Replaced
AC/DC Adapter - Wall Mount - 6 Watts: 9V @ 0.67A ++ NO AC INPUT BLADES ++ Lvl VI/T2
Search Keywords:
SMI69KP5
  This product is not in stock and cannot be back-ordered
MOQ for out of Stock Qty:
270
Please Note: Tariffs may apply for U.S. shipments
RECOMMENDED REPLACEMENT
SMI6B-9-K-P5
SMI6B-9-K-P5
