SMI36-24-K-P5
CUI Inc.AC/DC Adapter - Wall Mount - 36 Watts: 24V @ 1.5A ++ NO AC INPUT BLADES ++ Lvl VI/T2
Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
CUI Inc.
Part No:
SMI36-24-K-P5
RoHS:
Yes
HTS:
8504409510
COO:
CN
ECCN:
EAR99
Supplier Standard Pack
100
Package Type:
Box
Output Voltage:
24 VDC
Output Connector Type:
Barrel - Female
Output Connector Diameters:
2.1 x 5.5 mm
Overload Protection:
Yes
Over Voltage Protection:
Yes
Power Indicator:
No
Safety Approvals:
CCC, CE, cUL, PSE, RCM, UL
Line Regulation:
5.00 %
Ripple & Noise:
240 mV
Minimum AC Input Voltage:
90
Typical Hold-Up Time:
10ms(Min)
Output Connector Polarity:
Center Positive
Package Type:
Wall Plug
Maximum Input Current:
Not Spec'd
Output Type:
Fixed
Maximum Output Power:
36 W
Dimension:
78.5 x 35.5 x 66 mm
Thermal Protection:
No
Adapter Color:
Black
Minimum Input Voltage:
90Vac
Maximum Output Current:
1.5 A
Output Connector Angle:
Straight
Family:
SMI36
Input Frequency:
47 to 63 Hz
Dimensions LxWxH:
3.091 x 1.39 x 2.598 in
Short Circuit Protection:
Yes
Grade:
Commercial
AC Input Voltage:
90 to 264
Power:
36 W
Minimum DC Input Voltage:
Not App
Mounting:
External
Mounting Style:
External
Safety Class:
None
DOE Efficiency Level:
VI
Minimum Isolation Voltage:
3000Vac
Minimum Load (Amps):
0
Operating Temperature:
0 to 40 °C
Input Connector Type:
Interchangeable-Order Separately
Maximum AC Input Voltage:
264
Input Voltage:
90 to 264Vac
AC Input Current - Maximum:
0.58A
Input/Output Type:
AC/DC
Type:
Regulated-Switching
Number of Outputs:
1
Typical Inrush Current:
70A(Max) at 230Vac
Dimensions L x W x H:
78.5 x 35.5 x 66.0 mm
Efficiency:
Not Spec'd
Power Rating:
36 W
Special Features:
CoC Tier 2 Compliant, DoE Level VI Efficiency
Maximum Input Voltage:
264Vac
Maximum DC Input Voltage:
Not App
Dimensions L x W x H(in):
3.10 x 1.39 x 2.60 in
Style:
Interchangeable WallMount
PFC:
No
AC Input Current - Typical:
Not Spec'd
MOPP:
Not App
DC Input Voltage:
Not App
Load Regulation:
5.00 %
Output Current:
1.5 A
Output Cord Length:
1.5m (59.1in)
CoC Tier:
2
AC/DC Adapter - Wall Mount - 36 Watts: 24V @ 1.5A ++ NO AC INPUT BLADES ++ Lvl VI/T2
Search Keywords:
SMI3624KP5
IN STOCK:
0
MOQ for out of Stock Qty:
150
Factory Lead-Time
21 Weeks
Price (USD)
Quantity
Unit Price
Ext. Price
1
$22.65
$22.65
25
$18.15
$453.75
50
$17.42
$871.00
100
$16.72
$1,672.00
150
$16.64
$2,496.00
300
$15.79
$4,737.00
450
$15.58
$7,011.00
600
+
$15.38
$9,228.00
