PYB30-Q24-S15 by cui inc.
Image is representational - see mfr. specs
DATA SHEET

PYB30-Q24-S15

CUI Inc.

30 W, 4:1 Input Range, Single/Dual/Triple Regulated Output, 1500 Vdc Isolation, Dc-Dc Converter - 15 Vdc, 2 A, 30 W, 9~36 Vdc Input Range

RoHS Compliant
Tube Packaging
Accessories
Discontinued & Replaced
Accessories
This product is backed by Ecco Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
CUI Inc.
Part No:
PYB30-Q24-S15
RoHS:
Yes
HTS:
8504409580
COO:
CN
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Package Type:
Tube
Input Voltage:
9 to 36Vdc
Dimensions LxWxH:
2 x 1.6 x 0.47 in
Output Voltage:
15 VDC
Standard Footprint:
2" x 1.6"
Output Current:
2 A
Isolation:
1500 Vdc
Minimum Input Voltage:
12, 15, 18, 20, 24, 28, 30, 32, 36, 9 Vdc
Regulation:
Yes
Package Type:
DIP
Power:
30 W
Special Features:
Extended Temp Range, Output Trim, Remote On/Off Control
Number of Outputs:
1
Life Cycle:
Discontinued & Replaced
30 W, 4:1 Input Range, Single/Dual/Triple Regulated Output, 1500 Vdc Isolation, Dc-Dc Converter - 15 Vdc, 2 A, 30 W, 9~36 Vdc Input Range
Search Keywords:
PYB30Q24S15
  This product is not in stock and cannot be back-ordered
This product is no longer being manufactured but there may be alternatives. We can help you, Contact Us.
Older Equivalent
PYBE30-Q24-S15
PYBE30-Q24-S15
VIEW PRODUCT
Product Guides
PDF 3D Model
PDF Datasheet
