SCHURTER's SHF and SHT Fuse Series and FUS Fuseholder Series

SCHURTER’s high performance SHF and SHT fuses provide higher voltage, overcurrent, and short circuit protection in a universally accepted compact package size 6.3x32 mm. The SHF and SHT fuses offer 16 rated currents from 0.5A to 32A up to 500 VAC/VDC.

  • Quick-Acting…Primary protection up to 500 VAC/VDC. Breaking capacity up to 50kA VAC and 20kA VDC.
  • Time-Lag…Primary protection up to 500 VAC and 400 VDC. Breaking capacity up to 10kA VAC and 20kA VDC.
  • Applications for Fuses: 3-phase systems, Photovoltaic inverter to grid DC to AC or DC to DC, HVAC, Lighting systems, server farms and more.
  • The FUS series shock-safe, snap-in panel mount fuseholder is designed for robust applications and is IP67 weatherproof rated. The FUS is rated 16 A @ 500 VAC (IEC) and up to 32 A @ 600 VAC /VDC (UL/CSA). The fuseholder accepts 5x20 mm or 6.3 x 32 mm fuses.
  • Applications: Equipment exposed to outdoor weather, or oil and chemical, marine, medical, food processing, laboratory and mining environments.
See More
Show products manufactured by Schurter
授权经销商
访问网站
Information
产品规格范围 在线聊天 技术支持 产品说明书
产品指南

93 PRODUCT RESULTS FOR ""

Filter Results

93 PRODUCTS

    8020.5071
    产品说明书
    8020.5071 Schurter
    SHF 6.3x32, 2 A, 500 VAC, Quick-Acting F, Non-Resettable Fuse
    查看产品
    20 WEEKS
    30
    $0.6389
    250
    $0.5415
    1,000
    $0.5037
    2,500
    $0.4773
    5,000
    $0.4652
    8020.5071.G
    产品说明书
    8020.5071.G Schurter
    SHF 6.3x32, 2 A, 500 VAC, Quick-Acting F, Non-Resettable Fuse - 1,000 pc quantity
    查看产品
    20 WEEKS
    50
    $0.6212
    500
    $0.5047
    1,000
    $0.4821
    3,000
    $0.4549
    5,000
    $0.4425
    8020.5071.PT
    产品说明书
    8020.5071.PT Schurter
    SHT 6.3x32 Pigtail, 2 A, 500 VAC, Quick-Acting F, Non-Resettable Fuse, 6.3x32
    查看产品
    20 WEEKS
    1
    $0.6017
    100
    $0.5470
    300
    $0.5420
    1,000
    $0.5290
    2,500
    $0.5270
    8020.5072
    产品说明书
    8020.5072 Schurter
    SHF 6.3x32, 2.5 A, 500 VAC, Quick-Acting F, Non-Resettable Fuse
    查看产品
    20 WEEKS
    30
    $0.6389
    250
    $0.5415
    1,000
    $0.5037
    2,500
    $0.4773
    5,000
    $0.4652
    8020.5072.G
    产品说明书
    8020.5072.G Schurter
    SHF 6.3x32, 2.5 A, 500 VAC, Quick-Acting F, Non-Resettable Fuse - 1,000 pc quantity
    查看产品
    20 WEEKS
    50
    $0.6212
    500
    $0.5047
    1,000
    $0.4821
    3,000
    $0.4549
    5,000
    $0.4425
    8020.5072.PT
    产品说明书
    8020.5072.PT Schurter
    SHT 6.3x32 Pigtail, 2.5 A, 500 VAC, Quick-Acting F, Non-Resettable Fuse, 6.3x32
    查看产品
    20 WEEKS
    100
    $0.819
    300
    $0.666
    1,000
    $0.636
    2,500
    $0.584
    5,000
    $0.575
    8020.5073
    产品说明书
    8020.5073 Schurter
    SHF 6.3x32, 3.15 A, 500 VAC, Quick-Acting F, Non-Resettable Fuse
    查看产品
    20 WEEKS
    1
    $1.2309
    30
    $1.1190
    250
    $0.7420
    1,000
    $0.6460
    2,500
    $0.6190
    8020.5073.G
    产品说明书
    8020.5073.G Schurter
    SHF 6.3x32, 3.15 A, 500 VAC, Quick-Acting F, Non-Resettable Fuse - 1,000 pc quantity
    查看产品
    20 WEEKS
    1
    $0.6675
    50
    $0.6068
    500
    $0.4004
    1,000
    $0.3961
    3,000
    $0.3941
    8020.5073.PT
    产品说明书
    8020.5073.PT Schurter
    SHT 6.3x32 Pigtail, 3.15 A, 500 VAC, Quick-Acting F, Non-Resettable Fuse, 6.3x32
    查看产品
    20 WEEKS
    100
    $0.819
    300
    $0.666
    1,000
    $0.636
    2,500
    $0.584
    5,000
    $0.575
    8020.5074
    产品说明书
    8020.5074 Schurter
    SHF 6.3x32, 4 A, 500 VAC, Quick-Acting F, Non-Resettable Fuse
    查看产品
    20 WEEKS
    30
    $0.6389
    250
    $0.5415
    1,000
    $0.5037
    2,500
    $0.4773
    5,000
    $0.4652
